View this Vestas V27 wind turbine in full operation and see that the turbine had a new generator fitted in 2013. A fully Refurbished Gearbox was installed in 2007. Immediately Available! Can be disconnected from the grid and dismantled within days of a signed contract.
Vestas V27 Overview:
Fully refurbished Gearbox in 2007
New generator in 2013
Yaw gears are shifted
New contacts for yaw and hydraulic
Immaculate service history
MWPS World can assist in dismantling & transport at highly competitive prices
TECHNICAL SPECIFICATIONS:
Rated Output: 225/40kW – 400V
Rotor Diameter: 27m
Tower Height: 30m (one section ‘As Is’ or upon request- can be cut into two sections or three sections)
Flender Gearbox fully refurbished in 2007 by Breuer GmbH Germany
Generator Rating: 225 kW at 16 m/s
Rotor Speed: 43 rpm nominal
Cut-in Wind Speed: 3.5 m/s
Survival wind speed: 56 m/s
Rotor orientation: Upwind
Number of blades: 3
Blade material: Fibreglass/polyester
Control system Pitch controlled
Gearbox: Planetary
Brakes: Disc
Generator Asynchronous
Yaw control: Powered
Turbine Type: Pitch controlled
Build in 1991 – First commissioned in 1992
ABB Generator – Flender Gearbox
Sale Price includes:
Complete Turbine – Tower, Nacelle, Blades, Hub, Controller. Foundation top flange ring (worth £3,000 GBP)
Full-Service History
Seller will assist in dismantling and transportation to anywhere in the world
This Vestas V27 is still in operation and had a new generator fitted in 2013. A fully Refurbished Gearbox in 2007. Immediately Available! Can be disconnected from the grid and dismantled within days of signed contract and deposit received.
