Dismantle and Collect today for an ultra-cheap bargain!
Bergey’s slogan: “The wise choice for Performance, Reliability, and Ruggedness”
Apparently, the Bergey Excel 10 is ideal for homes, farms, and small businesses. Its extra-large rotor and low cut-in wind speed give it exceptional performance, out-producing all other wind turbines in its class. 30 years ago, Bergey pioneered the radically simple “three moving parts design” that has proven to provide the best reliability, service life, and value of all of the hundreds
of competitive designs that have come and gone in that time. A small wind turbine is a big investment and Bergey is clearly the wise choice.
TECHNICAL DATA & PERFORMANCE
START-UP WIND SPEED 5 mph (2.2 m/s)
CUT-IN WIND SPEED 5 mph (2.2 m/s)
RATED WIND SPEED 26 mph (11.6 m/s)
AWES RATED POWER (at 11 m/s or 25 mph) 8.9 kW
AWES ANNUAL ENERGY (at 5 m/s average) 13,600 kWh
CUT-OUT WIND SPEED none
FURLING WIND SPEED 36-40 mph (16-18 m/s)
MAXIMUM DESIGN WIND SPEED 134 mph (60m/s)
RATED POWER 10 kW ROTOR SPEED 0-400 RPM
MECHANICAL
TYPE 3-Blade Upwind, Horizontal-Axis
ROTOR DIAMETER 23 ft (7.0m)
WEIGHT 1020 lbs (460 kgs)
GEARBOX none
BLADE PITCH CONTROL none
OVERSPEED PROTECTION AUTOFURL®
TEMPERATURE RANGE -40 to 140 deg. F (-40 to 60deg. C)
ELECTRICAL
OUTPUT FORM 240VAC, 1-Phase, 60Hz
GENERATOR Permanent Magnet Alternator
Price includes:
Wind Generator, PowerSync II Inverter/Controller, 80ft lattice steel tower
